READY STOCK

Series Name

WM-B Series

Display
Screen Size

85"

Panel Technology

VA

Resolution

3,840 x 2,160

Brightness

350 nits

Contrast Ratio (Typical)

4000:1(without glass)

Viewing Angle (H/V)

178/178

Response Time

8ms

Operation Hours

16/7

Pixel Pitch (HxV)

0.4875(H) mm x 0.4875(W) mm

Color Gamut

72%

Glass Haze

2%(without glass)

H-Scanning Frequency

30~81kHz

Maximum Pixel Frequency

594Mhz

V-Scanning Frequency

48~75Hz

Connectivity
HDMI In

2

DVI In

1

USB

4 (A type : Front 2, Rear 1, C Type : Front 1)

RS232 In

Yes

RJ45 In

Yes

Wi-Fi

Yes

Bluetooth

Yes

Version of HDMI

2

Version of HDCP

2.2

Audio Output

Stereo Mini Jack

Verison of DP

1.2

Device Sharing

SmartView+, Airplay

Power
Power Supply

AC100-240V 50/60Hz

Power Consumption (On Mode)

528W(100-240V), 506W(220-240V), OPS(16V/4.5A) W

Power Consumption (Sleep Mode)

0.5W

Environmental Conditions
Operating Temperature

0℃~40℃

Operating Humidity

10 ~ 80%, non-condensing

Features
Touchscreen

Yes

Learning platform

MimioConnect Blended Learning platform

System On Chip

Yes

Touch
General Feature

IR

Dimensions
Packaging (W x H x D)

2136 x 1318 x 260 mm

Bezel Width

20.4mm(T/LR), 44.7mm(B)

Set Dimension (WxHxD)

1945.8 x 1151.1 x 89 mm

Weight
Product Weight

75.2 kg

Package Weight

91.6 kg

Service
Standard Warranty

5 Years

Accessories
Mount

Yes(Model Name : WMN8200SF)

Mechanical Specification
VESA Mount

600 x 400 mm

Frame Material

Metal (Aluminum)

SoC
OS Version

Tizen 6.5

Flash Memory Size

32GB

Certification and Compliance
EMC

Class A FCC (USA) Part 15, Subpart B, KCC/EK (Korea) Tuner : KN32 / KN35, Tunerless : KN32 / KN35 CE (Europe) EN55032 : 2012 or 2015, EN55024:2010 or EN 55035:2017 VCCI (Japan) VCCI CISPR32:2016, CCC(China) GB/T9254-2008, GB17625.1-2012 BSMI (Taiwan) CNS13438 ( ITE EMI ) CNS14336-1 ( ITE Safety ) CNS15663 (RoHS) , C-Tick (Australia) AS/NZS CISPR32:2015, GOST(Russia/CIS) ROCT CISPR 24-2013 　 ROCT CISPR 22:2005

Safety

CB (Europe) : IEC60950-1/EN60950-1CCC (China) : GB4943.1-2011PSB (Singapore ) : PSB+IEC60950-1NOM (Mexico ) : NOM-001-SCFI-1993IRAM (Argentina ) : IRAM+IEC60950-1SASO (Saudi Arabia ) : SASO+IEC60950-1BIS(India) : IEC60950-1 / IS13252NOM(Mexico) : Tuner : NOM-001-SCFI-1993 Tunerless : NOM-019-SCFI-1998KC(Korea) : K 60950-1EAC(Russia) : EAC+IEC60950-1INMETRO(Brazil) : INMETRO+IEC60950-1BSMI(Taiwan) : BSMI+IEC60950-1RCM(Australia) : IEC60950-1/AS/NZS 60950-1UL(USA) : cUL60950

Cisco Certified

Yes
