Display
Diagonal Size
75"

Panel Type
ADS

Resolution
3,840 x 2,160

Pixel Pitch (HxV, mm)
429.6 x 429.6

Brightness (Typ)
3500 nit

Contrast Ratio
1,200:1

Viewing Angle (H/V)
178/178

Response Time
14ms

Color Gamut
NTSC 72%

Glass Haze
2.5 %

H-Scanning Frequency
15~81KHz (HDMI), 30~135KHz (DP)

Maximum Pixel Frequency
77MHz

V-Scanning Frequency
24~75Hz (HDMI), 30~75Hz (DP)

Contrast Ratio (Dynamic)
Mega

Operation Time Support
24/7
Connectivity
HDMI In
2

DP In
1

Version of HDMI
2

Version of DP
1.2

Version of HDCP
2.2

USB
1

IR In
No

HDBaseT Out
No

Audio Out
Stereo Mini Jack

Power Out
No

RS232 In
Yes

RJ45 In
Yes

WiFi
No
Power
Power Supply
AC100-240V 50/60Hz

Power Consumption (On Mode, W)
1200W

Power Consumption (Sleep Mode, W)
0.5W
Dimension
Set Dimension (WxHxD, mm)
1774.8 x 1053.4 x 130 mm

Package Dimension (WxHxD, mm)
1932 x 1251 x 367 mm
Weight
Set Weight
134 kg

Package Weight
150 kg
Operation Conditions
Temperature
-30~+50 ℃

Humidity
10 ~ 80%, non-condensing
Mechanical Specification
Bezel Width (mm)
59.8

Glass Thickness
5T

Glass Film
IR-Cut Film

Frame Material
Metal (Aluminum)
Optional Feature
Protection Glass
Yes
SoC
OS Version
Tizen 5.0

Flash Memory Size
8GB
Certification and Compliance
EMC
Class A

Safety
60950-1
