Diagonal Size
75"

Panel Type
ADS

Resolution
3,840 x 2,160

Pixel Pitch (HxV)
429.6(H)×429.6(V)

Brightness (Typ)
400 nit

Contrast Ratio
1,200:1

Viewing Angle (H/V)
178/178

Response Time
8ms

Colour Gamut
72%

Glass Haze
25%

H-Scanning Frequency
135Khz

Maximum Pixel Frequency
78MHz

V-Scanning Frequency
60Hz

Operation Time Support
12/7
Connectivity
HDMI In
3

Version of HDMI
2

Version of HDCP
2.1

USB
5 (2.0 X1, 3.0X4)

IR In
Yes

Audio In
Stereo Mini Jack

Audio Out
Stereo Mini Jack

Video Out
Yes

RS232 In
Yes

RS232 Out
Yes

RJ45 In
Yes

RJ45 Out
Yes

WiFi
Yes

Bluetooth
Yes
Power
Power Supply
AC100-240V 50/60Hz

Power Consumption (On Mode)
385W

Power Consumption (Sleep Mode)
0.5W↓
Dimension
Set Dimension (WxHxD)
1709 x 1020 x 88 mm

Package Dimension (WxHxD)
1863 x 1140 x 225 mm
Weight
Set Weight
45.5 kg

Package Weight
57.6 kg
Operation Conditions
Temperature
0℃~40℃

Humidity
10 ~ 90%
Mechanical Specification
VESA Mount
800 x 400 mm

Bezel Width
16.4mm(U), 16.4mm(L/R), 44.9mm(B)

Bezel Color
Space Gray

Frame Material
Non-Glossy
Optional Feature
Touch
Yes
SoC
OS Version
Android-13

Flash Memory Size
64GB
Touch
Touch Technology
IR
Certification and Compliance
EMC
Part 15, Subpart B Class A KS C9832, KS C9835 EN55032:2015/A11:2020/A1:2020,EN 55035:2017/A11:2020 EN 61000-3-2:2019/A1:2021 ?? ? ? ? ? ? EN 61000-3-3:2013/A1:2019/A2:2021 EN 61000-3-2:2019/A1:2021 ?? ? ? ? ? ? EN 61000-3-3:2013/A1:2019/A2:2021 EN 61000-3-2:2019/A1:2021 ?? ? ? ? ? ? EN 61000-3-3:2013/A1:2019/A2:2021 EN 55035:2017/A11:2020 EN 61000-3-2:2019/A1:2021 ?? ? ? ? ? ? EN 61000-3-3:2013/A1:2019/A2:2021 J55032 , VCCI-CISPR32 JIS C61000-3-2 GB9254-2021 GB17625.1-2012 CNS13438 (ITE EMI) Class A /? AS/NZS? CISPR 32 EN55032:2015/A11:2020/A1:2020,EN 55035:2017/A11:2020

Safety
IEC 62368-1 Edtion 3&IEC 60950-1 UL62368-1 edition 3 GB4943.1-2022 PSB+ IEC 62368-1 NOM-019 K 62368 IRAM+ IEC 62368-1 EAC+ IEC 62368-1 INMETRO+ IEC 62368-1 SASO+ IEC 62368-1 BSMI+ IEC 62368-1 IEC 62368-1/AS/NZS 62368-1 IEC60950-1 / IS13252
