READY STOCK

Ukuran 55" (55 inch)

Display
Screen Size

55"

Panel Technology

VA

Resolution

3,840 x 2,160

Brightness

500 nit (without Glass)

Contrast Ratio (Dynamic)

Mega

Viewing Angle (H/V)

178/178

Response Time

8ms

Operation Hours

24/7

Pixel Pitch (HxV)

0.315 x 0.315 (mm)

Brightness (Typical)

500(without Glass), 400(with glass) nit

Response Time (ms)

8ms

Color Gamut

92% (DCI-P3, CIE 1976) %

Glass Haze

25% (without glass) %

H-Scanning Frequency

30 ~ 81 kHz

Maximum Pixel Frequency

594MHz

V-Scanning Frequency

48 ~ 75 kHz

Operation Time Support

24/7

Connectivity
HDMI In

3

DP In

1

USB

2

IR In

Yes

Audio Out

Stereo Mini Jack

RS232 In

Yes

RS232 Out

Yes

RJ45 In

Yes

Wi-Fi

Yes

Bluetooth

Yes

Version of HDMI

2

Version of HDCP

2.2

Verison of DP

1.2

Power
Power Supply

AC 100 - 240 V, 50/60 Hz

Power Consumption (On Mode)

143W W

Power Consumption (Sleep Mode)

0.5W W

Max[W/h]

143

Typical[W/h]

108

Environmental Conditions
Operating Temperature

0℃~40℃ ℃

Operating Humidity

10 ~ 80%, non-condensing %

Features
Key

UHD Signage with Built-in MagicInfo S10, SSSP 10.0

H/W

Symmetric Design (same with QxR) Center IR Temperature Sensor Auto Level Wi-Fi(2.4/5.0GHz dual) & BT

S/W

Workspace (Microsoft365/VMWare/RDP) Custom Home Auto Source Switching & Recovery Dicom Simulation Mode Director Mode Upgradable Web-Engine Tizen Enterprise Platform Video Conference Solution [end of June~] Smart Calibration

Touchscreen

Yes

Touch
Touch Technology

Capative

Internal Player
Processor

Cortex A72 1.7GHz Quad-Core CPU

Storage

16 GB

Operating System

Tizen 6.5

Dimensions
Packaging (W x H x D)

1421 x 884 x 165

Set Dimension (WxHxD)

1253.8 x 734.6 x 56.7

Package Dimensions (W x H x D)

1421 x 884 x 165 mm

Weight
Package Weight

32.5

Set Weight

26.9

Accessories
Included in Box

Quick Setup Guide, Warranty Card, Power Cord RS232C(IN) Gender Remote Controller & Batteries

Stand

STN-L4355G

Mount

WMN4070SG (Land Only) WMN750ME

Specialty

CML400XR

Mechanical Specs
VESA Mount

200 X 200

Bezel Width (mm)

26.0/26.0/21.0/21.0 (U/D/L/R)

Operation Conditions
Temperature

0℃~ 40℃

Humidity

10~80%

Mechanical Specification
VESA Mount

200 x 200 mm

Frame Material

Non-Glossy

Optional Feature
Touch

Yes

Mount

WMN4070SG

Stand

STN-L4355G

SoC
OS Version

Tizen 6.5

Flash Memory Size

16GB

Certification and Compliance
EMC

Class B

Safety

60950-1 / 62368-1

Environment

ENERGY STAR 8.0, EPEAT

IP Rating

IP5x

Security

802.1x(WPA2 Enterprise) : EAP-TLS, EAP-TTLS, EAP-PEAP

Display Panel
Class

55

Measured

54.6" / 138.7cm

Resolution

3840x2160(16:9)

Orientation

Landscape / Portrait

Haze

25% (without Glass)

Contrast Ratio (Typ)

4000:1

General Feature

VA

Active Display Area

1209.6(H) x 680.4(V)

Pixel Pitch (mm)

0.315 x 0.315

Brightness (Typ.)

500 nit (without Glass)

Color Gamut

92% (DCI-P3, CIE 1976)

Operation Hour

24/7

Connectivity / Sounds
Video

DP 1.2 (1), HDMI 2.0 (3)

USB

USB 2.0 x 2

HDCP

HDCP2.2

USB

Touch out 2 (PC/screen)

Audio

Stereo mini Jack

External Control

RS232C(in/out), RJ45

Speaker

10W 2ch
