Specifications

Sensor: 1/3 "Progressive Scan CMOS Sensor
Minimum illumination: Color: 0.008 lux (F1.2, auto gain on); B / W: 0 lux (IR on)
Dynamic range: up to 120 dB
Focal length:

5.3 ̴ 64 mm (12x optical zoom)

Viewing Angles (D / W):

57 ° ̴ 4 ° / 35 ° ̴ 2 °

Aperture Control: DC
Shutter Speed: 1/100000 - 1/5 s
Lens Approach Speed: 3.1s (Wide-Tele)
Minimum working distance: 1000 ~ 1500 mm (Wide-Tele)
Angle of rotation: 360 °, infinite rotation
Turning speed: in manual mode: 0.2 ° ~ 60 ° / s, at a preset position 100 ° / s
Tilt Angle: -45 ° ~ 30 °
Tilt speed: in manual mode 0.2 ° ~ 30 ° / s, at a preset position 60 ° / s
PTZ functions: 255 presets, 8 programmable tours (up to 48 presets each), 4 learnable tours, position restoration when power is restored, the ability to display PTZ coordinates, 3D positioning
Maximum Resolution

first stream: 2592 × 1520

second stream: 704 × 576

third stream: 1920 × 1080

Maximum frame rate: 20 fps at 2592 × 1520 pixels .; 30 fps (for all other resolutions and optionally for 2592 × 1520 pixels.)
Video Bitrate: 16 Kbps - 16 Mbps (CBR / VBR Configurable)
Video Compression Codec: H.265 + / H.265 (HEVC) /H.264+/H.264/MJPEG
Audio Compression Codec: G .711 / ACC
Network Protocols: IPv4 / IPv6, TCP, UDP, RTP, RTSP, RTCP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP, UPnP, SIP, PPPoE, VLAN, 802.1x, QoS
Compatibility: ONVIF Profile S & G, CGI, SDK
Events: motion detection, loss of network connection, sound detection
Event-driven actions:

AVI / JPG to FTP / NAS / SD

SIP call

JPG to SMTP

HTTP Notification (Notifications with authorization)

Additional functions: motion detection, hiding private areas, BLC, HLC, 3D-DNR, ROI, Anti-fog
Built-in analytics (optional)

Entrance to the zone, exit from the zone, advanced detection of movement, determination of impact, crossing the line, loitering, determination of a person, counting people

physical characteristics

Network Interface: 1 RJ45 10M / 100M Ethernet
SD / SDHC / SDXC card slot up to 128 GB
Options: alarming interfaces (1 in / 1 out); audio input / audio output: 1/1
IR illumination range: up to 100 m
IP66 dust and water tightness
Operating temperature: -40 ℃ to + 60 ℃
Humidity: 0-90% (non-condensing)
Power: PoE (802.3at); 12V ± 10% DC
Consumption: 10.5 W (max.) (20 W max. With IR)
Dimensions, mm: 160 × 273.5 × 210 (with wall mount); 218 × 120 × 172 (with pedestal mount)
Weight: 2000g (with wall mount); 1800g (with pedestal mount)
